BR1001, BR1005 SINGLE-PHASE SILICON BRIDGE RECTIFIER

Sunmate

Description

BR1005-BR1010 SINGLE-PHASE SILICON BRIDGE RECTIFIER VOLTAGE RANGE: 50 - 1000V CURRENT: 10 A .

📥 Download Datasheet

BR1001 Datasheet Preview — This datasheet PDF includes multiple part numbers: BR1001, BR1005. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: BR1001, BR1005
Manufacturer: Sunmate
File Size: 451.71 KB
Datasheet: BR1005-Sunmate.pdf
Description: SINGLE-PHASE SILICON BRIDGE RECTIFIER
Note: This datasheet PDF includes multiple part numbers: BR1001, BR1005.
Please refer to the document for exact specifications by model.

Features

* ! Low cost ! Low forward voltage ! Low leakage current Mechanical Data ! Case: Molded plastic body ! Terminal: Lead solderable per MIL-STD-202E method 208C. ! Polarity: Polarity symbols molded on case ! Mounting position: Any ! Weight:0. 20ounce, 5.62 grams BR-10 .296(7.5) .255(6.5) .052(1.3) DIA.
