SMDJ7.5C, SMDJ5.0 - SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR DIODE

Sunmate

Datasheet Details

Part number	SMDJ7.5C, SMDJ5.0
Manufacturer	Sunmate
File Size	748.97 KB
Description	SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR DIODE
Datasheet	SMDJ5.0-Sunmate.pdf
Note	This datasheet PDF includes multiple part numbers: SMDJ7.5C, SMDJ5.0. Please refer to the document for exact specifications by model.

! Glass Passivated Die Construction ! Uni- and Bi-Directional Versions Available ! Excellent Clamping Capability ! Fast Response Time ! Plastic Case Material has UL Flammability Classification Rating 94V-O Mechanical Data ! Case: SMC/DO-214AB, Molded Plastic ! Terminals: Solder Plated, Solderable per MIL-STD-750, Method 2026 ! Polarity: Cathode Band or Cathode Notch ! Marking: Type Number ! Weight: 0.21 grams (approx. ) SMC/DO-214AB B Dim Min Max A 5.59 6.22 A C B 6.60 7.11 C 2.75 3.18 D 0.15.
