HV311 - Hot Swap Controller

Datasheet Summary

Description

The Supertex HV311 Hot Swap Controller provides inrush current limiting and other power supply support functions for hot swap equipment.

Current limiting is provided by control of an external MOSFET which is placed in the return line of the power supply connection.

Features

  • 10 to 90V operation, positive or negative supply.
  • UV/OV lock out & power-on-reset.
  • Circuit breaker.
  • 100ms startup timer.
  • Automatic retry or latched operation.
  • Low Power, 400µA sleep mode.
  • Active low power good.
  • 8-Lead SOIC package General.

📥 Download Datasheet

Datasheet preview – HV311

Datasheet Details

Part number HV311
Manufacturer Supertex Inc
File Size 0.97 MB
Description Hot Swap Controller
Datasheet download datasheet HV311 Datasheet
Additional preview pages of the HV311 datasheet.

📁 Similar Datasheet

Other Datasheets by Supertex Inc
  • HV310 - Inrush Current Limiter Controllers
  • HV312 - Sequencing Hotswap Controllers
  • HV3137 - 64-Channel Serial To Parallel Converter With Open Drain Outputs
  • HV300 - Inrush Current Limiter Controllers
  • HV301 - Hotswap/ Controllers with Circuit Breaker
  • HV302 - Sequencing Hotswap Controllers
  • HV3418 - 64-Channel Serial to Parallel Converter
  • HV3922 - High Voltage PIN Diode Driver

Full PDF Text Transcription

Click to expand full text
HV311 Hot Swap Controller Features ► 10 to 90V operation, positive or negative supply ► UV/OV lock out & power-on-reset ► Circuit breaker ► 100ms startup timer ► Automatic retry or latched operation ► Low Power, 400µA sleep mode ► Active low power good ► 8-Lead SOIC package General Description The Supertex HV311 Hot Swap Controller provides inrush current limiting and other power supply support functions for hot swap equipment. Current limiting is provided by control of an external MOSFET which is placed in the return line of the power supply connection. Placement in the return allows use of an N-channel MOSFET without the need for high side driving.
