1.5SMCJ11A Datasheet - TAITRON

1.5SMCJ11A 1500W Surface Mount Transient Voltage Suppressor

Value PPPM IPPM Peak Pulse Power Dissipation on 10/1000 us waveform Peak Pulse.

1.5SMCJ11A Features

* Low inductance, excellent clamping capability

* Repetition rate(duty cycle): 0.05%

* Fast response time: typically less than 1.0ps from 0V to BV min.

* Typical IR less than 1 µA above 10V SMC

* High temperature soldering guaranteed 250°C/10 seconds at t

Datasheet Details

1.5SMCJ11A

TAITRON

181.63 KB

1500w surface mount transient voltage suppressor.
