DF206S, DF2005S - 2.0A Glass Passivated Bridge Rectifier

TAITRON

The DF206S by TAITRON is a 2.0A Glass Passivated Bridge Rectifier. Below is the official datasheet preview.

Datasheet Details

Part number	DF206S, DF2005S
Manufacturer	TAITRON
File Size	347.19 KB
Description	2.0A Glass Passivated Bridge Rectifier
Datasheet	DF2005S-TAITRON.pdf
Note	This datasheet PDF includes multiple part numbers: DF206S, DF2005S. Please refer to the document for exact specifications by model.
Additional preview pages of the DF206S datasheet.

Glass passivated chip junction.
Low leakage.
High surge current capability.
Ideal for printed circuit boards DFMS.
Reliable low cost construction utilizing molded plastic technique.
High temperature soldering guaranteed: 260˚C/10 seconds at 5lbs. (2.3kg) tension.
Small size, simple installation.
RoHS compliant Mechanical Data Case: Epoxy: Terminals: Polarity: Weight: DFMS, Molded plastic body over passivated junct.
