DEA105425BT-1293A1 Datasheet - TDK

DEA105425BT-1293A1 Multilayer Band Pass Filter

RF Components June 2015 Multilayer Band Pass Filter For 4900 5950MHz DEA105425BT-1293A1 1.0x0.5mm [EIA 0402] Dimensions Code JIS[EIA] RF Components Multilayer Band Pass Filter For 4900 5950MHz DEA105425BT-1293A1 SHAPES AND DIMENSIONS [Top view] 1.00±0.08 (4) (1) (3) 0.45max. (2) Marking 0.50±0.08 [Bottom view] 0.12+0.12/ 0.10 0.30±0.15 0.30±0.15 0.35±0.15 0.12+0.12/ 0.10 Terminal functions 1 IN 2 GND 3 OUT 4 GND Dimensions in mm RECOMMEND.

DEA105425BT-1293A1-TDK.pdf

Preview of DEA105425BT-1293A1 PDF
DEA105425BT-1293A1 Datasheet Preview Page 2 DEA105425BT-1293A1 Datasheet Preview Page 3

Datasheet Details

Part number:

DEA105425BT-1293A1

Manufacturer:

TDK

File Size:

67.80 KB

Description:

Multilayer band pass filter.
