TPE2405D

1W 1.5KVDC and 2KVDC Isolated Single Output DC/DC Converters

TOPPOWER

TPE2405D Features

* RoHS compliant、CE certification Efficiency up to 81% Footprint from 0.69cm2 Output voltage: 3.3V,5V, 9V, 12V,15V,24V SELECTION GUIDE Single isolated output Power density1.45W/cm3 Industry Standard Pinout Custom solutions available SIP:1.5KVDC isolation DIP: 2KVDC isolation UL 94V-0 Package materi

TPE2405D General Description

1W 1.5KVDC and 2KVDC Isolated Single Output DC/DC Converters The TPE series are miniature, isolated 1W DC/DC converters in a SIP and DIP package. They offer the ideal solution in many space critical applications for board level power distribution. The internal SMD construction makes it possible to .

TPE2405D Datasheet (585.25 KB)

TPE2405D Datasheet Preview — Preview of TPE2405D PDF

Datasheet Details

Part number:

TPE2405D

Manufacturer:

TOPPOWER

File Size:

585.25 KB

Description:

1w 1.5kvdc and 2kvdc isolated single output dc/dc converters.
