1N4755A - GLASS PASSIVATED JUNCTION SILICON ZENER DIODE

1N4755A Description

1N4741A THRU 1M200Z GLASS PASSIVATED JUNCTION SILICON ZENER DIODE VOLTAGE - 11 TO 200 Volts Power - 1.0 Watt DO-41 .

1N4755A Features

* l l l l l l l Low profile package Built-in strain relief Glass passivated junction Low inductance Typical IR less than 5.0 A above 11V High temperature soldering : 260 /10 seconds at terminals Plastic package has Underwriters Laboratory Flammability Classification 94V-O MECHANICAL DATA Case: Mold

📥 Download Datasheet

Preview of 1N4755A PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
1N4755A
Manufacturer
TRSYS
File Size
348.88 KB
Datasheet
1N4755A_TRSYS.pdf
Description
GLASS PASSIVATED JUNCTION SILICON ZENER DIODE
