OPB826S, OPB822S Datasheet - TT

OPB826S Dual Channel Encoder

Non-contact switching Single or double apertures for high resolution Choice of slot widths Choice of side-by-side or over/under dual channels Choice of electrical outputs OPB826 OPB822 Each OPB822 and OPB826 slotted switch consists of two infrared emitting diodes and two NPN silicon phototransistors mounted on opposite sides of a 0.090” (2.29 mm) wide slot (OPB822) or a 0.100” (2.54 mm) wide slot (OPB826). OPB822 uses an side-by-side mounting configuration, while.

OPB822S-TT.pdf

This datasheet PDF includes multiple part numbers: OPB826S, OPB822S. Please refer to the document for exact specifications by model.
OPB826S Datasheet Preview Page 2 OPB826S Datasheet Preview Page 3

Datasheet Details

Part number:

OPB826S, OPB822S

Manufacturer:

TT

File Size:

1.05 MB

Description:

Dual channel encoder.

Note:

This datasheet PDF includes multiple part numbers: OPB826S, OPB822S.
Please refer to the document for exact specifications by model.
