1N6274, 1N6276CA Transient Voltage Suppressor Diodes

1N6274 Description

1.5KE SERIES Transient Voltage Suppressor Diodes Voltage Range 6.8 to 440 Volts 1500 Watts Peak Power 5.0 Watts Steady State .

1N6274 Features

* UL Recognized File # E-96005 Plastic package has Underwriters Laboratory Flammability Classification 94V-0 Exceeds environmental standards of MIL-STD-19500 1500W surge capability at 10 x 100 us waveform, duty cycle: 0.01% Excellent clamping capability Low zener impedance Fast response time: Typicall

1N6274 Applications

* Notes: 1. For Bidirectional Use C or CA Suffix for Types 1.5KE6.8 through Types 1.5KE440. Notes: 2. Electrical Characteristics Apply in Both Directions. - 576 Free Datasheet http://www. datasheet4u. com/ RATINGS AND CHARACTERISTIC CURVES (1.5KE SERIES) FIG.1- PEAK PULSE POWER RATING CURVE PEAK PULSE

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: 1N6274, 1N6276CA. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
1N6274, 1N6276CA
Manufacturer
Taiwan Semiconductor
File Size
191.91 KB
Datasheet
1N6276CA_TaiwanSemiconductor.pdf
Description
Transient Voltage Suppressor Diodes
Note
This datasheet PDF includes multiple part numbers: 1N6274, 1N6276CA.
Please refer to the document for exact specifications by model.
