BZD27C56P, BZD27C6V8P, 10V - 220V Zener Diode

BZD27C10P * BZD27C220P Taiwan Semiconductor 1W, 10V - 220V Zener Diode .

datasheet Preview Page 1 from Datasheet4u.com

BZD27C6V8P-TaiwanSemiconductor.pdf

BZD27C56P Datasheet Preview — This datasheet PDF includes multiple part numbers: BZD27C56P, BZD27C6V8P. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

BZD27C56P, BZD27C6V8P

Manufacturer:

Taiwan Semiconductor

File Size:

463.87 KB

Description:

10V - 220V Zener Diode

Note:

This datasheet PDF includes multiple part numbers: BZD27C56P, BZD27C6V8P.
Please refer to the document for exact specifications by model.

Features

* Silicon zener diodes
* Low profile surface-mount package
* Zener and surge current specification
* Low leakage current
* Excellent stability
* Moisture sensitivity level: level 1, per J-STD-020
* RoHS Compliant

Applications

* Voltage regulating
* Reference voltage
* Protection circuit KEY PARAMETERS PARAMETER VALUE UNIT VZ 10 - 220 V Test current IZT 5 - 50 mA Ptot 1 W TJ MAX 175 °C Package Sub SMA Configuration Single die MECHANICAL DATA
* Case: Sub SMA
* Molding compound meets U
