SMAJ70A Surface Mount Transient Voltage Suppressor

SMAJ70A Features

* Ideal for automated placement

* Glass passivated chip junction

* Excellent clamping capability

* Fast response time: Typically less than 1.0ps from 0 V to BV min

* Typical IR less than 1μA above 10V

* 400W peak pulse power capability with a 10/1000μs waveform (300W above 78

Datasheet Details

SMAJ70A, SMAJ5.0

Taiwan Semiconductor

520.82 KB

Surface mount transient voltage suppressor.

This datasheet PDF includes multiple part numbers: SMAJ70A, SMAJ5.0.
Please refer to the document for exact specifications by model.
