TB15.A2V, TB10A2V Current Transducers

TB15.A2V Description

Topstek Current Transducer TB5A ..50A 2V-S12 TB 5A..50A-2V-S12 .

TB15.A2V Features

* Highly reliable Hall Effect device
* Compact and light weight
* Fast response time
* Excellent linearity of the output voltage over a wide input range
* Excellent frequency response (> 50 kHz)
* Low power consumption (12 mA nominal)
* Capable

TB15.A2V Applications

* UPS systems
* Industrial robots
* NC tooling machines
* Elevator controllers
* Process control devices
* AC and DC servo systems
* Motor speed controller
* Electrical vehicle controllers
* Inverter-controlled welding machines

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: TB15.A2V, TB10A2V. Please refer to the document for exact specifications by model.
datasheet Preview Page 2

Datasheet Details

Part number
TB15.A2V, TB10A2V
Manufacturer
Topstek
File Size
236.98 KB
Datasheet
TB10A2V-Topstek.pdf
Description
Current Transducers
Note
This datasheet PDF includes multiple part numbers: TB15.A2V, TB10A2V.
Please refer to the document for exact specifications by model.
