XC9802

Regulated Voltage Step-Up Charge Pump

Image Manufacturer B2B MPN Description Distributor Stock Quantity Price Buy Now
Distributor Torex Semiconductor LTD XC9802B333ER-G IC REG BOOST 3.3V 80MA USP-8B05 DigiKey 100 2500 units
$0.87

XC9802 Datasheet (1.69 MB)

Preview of XC9802 PDF

Datasheet Details

Part number:

XC9802

Manufacturer:

Torex Semiconductor

File Size:

1.69 MB

Description:

Regulated voltage step-up charge pump.

XC9802 Features

* Input Voltage Range : 1.8V ~ 5.5V Output Voltage Range : 2.5V ~ 6.0V Small Input Current : 80μA (no load:XC9802) Output Current : 80mA (3.6V→5.0V step-up) Oscillation Frequency : 300 kHz Stand-by Current (CE ’L’) : 2.0μA (MAX.) PFM Operation During Light Loads (XC9802) CE (Chip Enable)

XC9802 General Description

The XC9801 series are fixed regulated voltage step-up charge pump ICs which provide stable, highly efficient, positive voltages with the only external components required being 2 capacitors. Since regulating is done via the control of the charge pump's gate voltage waveform, ripple is minimal. Outpu.
