2SK240
FEATURES
- Remended for first stages of EQ Amplifiers.
- High |y fs l : lyf s l=22m S(Typ.)
(VDS =10V, VGS =0, I DS s=3m A)
- Excellent Pair Characteristics
: I VGS1 -VGS2 |=20m V (Max.)
(VDS =10V, I D =lm A)
- High Breakdown Voltage :
'GDS =-40V (Min.)
- Low Noise en =0.95n V//Hz (Typ.)
(VDS =10V, l D=lm A, f=lk Hz)
- High Input Impedance : l GSS="ln A(Max.) (v GS =-30V)
- plementary to 2SJ75.
MAXIMUM RATINGS (Ta=25°C) CHARACTERISTIC
Gate-Drain Voltage Gate Current Drain Power Dissipation Junction Temperature Storage Temperature Range
SYMBOL
VGDS IG PD Ti Tstg
RATING -40 10
400x2 125
-55^125
UNIT V m A m W
°C °C
S4MAX.
Unit : mm
X < s
X < s o
[
'
0.45 J J t^
Oi
| i-i
1 1.27
123 1. DRAIN 1 2. GATE 1 3. SOURCE...
