TB1231CN - PAL/NTSC IF+VCD PROCESSOR

Product Overview

Toshiba

📥 Download Datasheet

TB1231CN PAL/NTSC IF+VCD PROCESSOR by Toshiba - Datasheet Preview — Datasheet preview – TB1231CN

Datasheet Details

Part number	TB1231CN
Manufacturer	Toshiba
File Size	3.21 MB
Description	PAL/NTSC IF+VCD PROCESSOR
Datasheet	TB1231CN Datasheet
Additional preview pages of the TB1231CN datasheet.

Product details

Features

IF stage.
lntercarrier Input.
Double Time Constant IF AGC.
Bus Controlled RF AGC.
Bus Controlled PIF VCO.
L-SECAM Demodulation.
PLL SIF Demodulation (For 4.5-6.5MHz multi-SIF, Thank coil-less) Video stage.
Built-in Video Switch (2 Inputs/ 1 Output).
Built-in Chroma Trap.
Built-in Y Delay Line.
Black Expansion.
DL Type Sharpness Control Chroma stage.
1 X'tal for Multi-System (3.58MHz I 4.43.
