LM2594 - DC/DC converter

Name: LM2594
SKU: LM2594-1587752

📥 Download Datasheet

LM2594 Datasheet Preview — Preview of LM2594 PDF

Datasheet Details

Part number	LM2594
Manufacturer	UMW
File Size	763.27 KB
Description	DC/DC converter
Datasheet	LM2594-UMW.pdf

LM2594 Product details

Description

The LM2594(HV) is a 150 KHz fixed frequency PWM buck (step-down)DC/DC converter, capable of driving a 1.5A load with high efficiency, low ripple and excellent line and load regulation.

Features

n Wide 4.5V to 40V Input Voltage Range n 3.3V,5V,12V, and adjustable versions n Output Adjustable from 1.23V to 37V (57 V for the HV Version) n Maximum Duty Cycle 100% n Minimum Drop Out 1.5V n Fixed 150KHz Switching Frequency n 1.5A Constant Output Current Capability n Internal Optimize Power Transistor n High efficiency n Excellent line and load regulation n TTL shutdown capability n ON/OFF pin with hysteresis function n Built in thermal shutdown function n Built in current limit function n Bu.
