42HK7401-XX Datasheet - UMot

42HK7401-XX Hybrid Stepper Motor

0.9°42mm Hybrid Stepper Motor General Specifications Item Step Angle Step Angle Accuracy Resistance Accuracy Inductance Accuracy Temperature Rise Ambient Temperature Insulation Resistance Dielectric Stregth Radial Runout Axial Runout Radial Load Axial Load Specifications 0.9° ±5% ±10% ±20% 80℃ Max(Rated Current,2 phase power) -20℃ - +50℃ 100MΩMin,500VDC 500VAC,1 minute 0.02 Max.(450g load) 0.08 Max.(450g load) 28N(20mm from Flange) 10N The Performan.

42HK7401-XX Datasheet (576.59 KB)

Preview of 42HK7401-XX PDF
42HK7401-XX Datasheet Preview Page 2 42HK7401-XX Datasheet Preview Page 3

Datasheet Details

Part number:

42HK7401-XX

Manufacturer:

UMot

File Size:

576.59 KB

Description:

Hybrid stepper motor.
