UR7636H 36-V INPUT VOLTAGE 500MA ULTRA LOW IQ VOLTAGE REGULATOR

The UTC UR76XXH Series are a low dropout regulator with wide input voltage range, high output voltage accuracy, ultra low quiescent current and low dropout. This regulator is based on a CMOS process, and it’s input voltage could high enough more than 36V, thus they are very suitable for high voltage.

UR7636H Features

* High output voltage accuracy: ±2%

* Ultra low quiescent current: 6uA /15uA (Typ.)

* Low temperature-drift coefficient of VOUT: ±100 ppm/°C (Typ.)

* Wide Input voltage range: 2.5~36V CMOS IC 3 12 SOT-23-3 (JEDEC TO-236) 4 5 1 23 SOT-25 (JEDEC MO-178) SOP-8

* ORDERING INFORMATI

UR7633H-UTC.pdf

UR7636H Datasheet Preview — This datasheet PDF includes multiple part numbers: UR7636H, UR7633H. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

UR7636H, UR7633H

Manufacturer:

UTC

File Size:

226.36 KB

Description:

36-v input voltage 500ma ultra low iq voltage regulator.

Note:

This datasheet PDF includes multiple part numbers: UR7636H, UR7633H.
Please refer to the document for exact specifications by model.
