UJ4C075018K3S
Description
The UJ4C075018K3S is a 750V, 18m W G4 Si C FET. It is based on a unique ‘cascode’ circuit configuration, in which a normally-on Si C JFET is co-packaged with a Si MOSFET to produce a normally-off Si C FET device. The device’s standard gate-drive characteristics allows for a true “drop-in replacement” to Si IGBTs, Si FETs, Si C MOSFETs or Si superjunction devices. Available in the TO-247-3L package, this device exhibits ultra-low gate charge and exceptional reverse recovery characteristics, making it ideal for switching inductive loads and any application requiring standard gate drive.
1 23
Part Number UJ4C075018K3S
G (1)
Package TO-247-3L
Features
S (3) w On-resistance RDS(on): 18m W (typ) w Operating temperature: 175°C (max) w Excellent reverse recovery: Qrr = 102n C w Low body diode VFSD: 1.14V w Low gate charge: QG = 37.8n C w Threshold voltage VG(th): 4.8V (typ) allowing 0 to 15V drive w Low intrinsic capacitance w ESD protected, HBM class 2
Marking UJ4C075018K3S
Typical...
