DG308B - Improved Quad CMOS Analog Switches

Product Overview

Vishay Siliconix

📥 Download Datasheet

DG308B Improved Quad CMOS Analog Switches by Vishay Siliconix - Datasheet Preview — Datasheet preview – DG308B

Datasheet Details

Part number	DG308B
Manufacturer	Vishay Siliconix
File Size	243.14 KB
Description	Improved Quad CMOS Analog Switches
Datasheet	DG308B Datasheet
Additional preview pages of the DG308B datasheet.

Product details

Description

The DG308B, DG309B analog switches are highly improved versions of the industry-standard DG308A, DG309.

Features

± 22 V supply voltage rating.
CMOS compatible logic.
Low on-resistance - RDS(on): 45 .
Low leakage - ID(on): 20 pA.
Single supply operation possible.
Extended temperature range.
Fast switching - tON: < 200 ns.
Low glitching - Q: 1 pC.
