SMP20 - (SMPxx) Transient Voltage Suppressors

Product Overview

Vishay Siliconix

Part number	SMP20
Manufacturer	Vishay Siliconix
File Size	98.46 KB
Description	(SMPxx) Transient Voltage Suppressors
Datasheet	SMP20 Datasheet
Note	This datasheet PDF includes multiple part numbers: SMP20, SMP26. Please refer to the document for exact specifications by model.
Additional preview pages of the SMP20 datasheet.

Very low profile - typical height of 1.0 mm.
Ideal for automated placement.
Available in uni-directional.
400 W peak pulse power capability with a 10/1000 μs waveform.
Excellent clamping capability.
Very fast response time.
Low incremental surge resistance.
Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C.
Material categorization: for definitions of compliance please see www. vishay. com/doc?99912.
