BAV20W-G
FEATURES
- Silicon epitaxial planar diodes
- For general purpose
- AEC-Q101 qualified available (part number on request)
- Base P/N-G3
- green, mercial grade
- Material categorization: for definitions of pliance please see .vishay./doc?99912
PARTS TABLE
PART
TYPE DIFFERENTIATION
BAV19W-G BAV20W-G BAV21W-G
VR = 100 V VR = 150 V VR = 200 V
ORDERING CODE
BAV19W-G3-08 or BAV19W-G3-18 BAV20W-G3-08 or BAV20W-G3-18 BAV21W-G3-08 or BAV21W-G3-18
TYPE MARKING
AS AT AU
CIRCUIT CONFIGURATION
Single Single Single
REMARKS
Tape and reel Tape and reel Tape and reel
ABSOLUTE MAXIMUM RATINGS (Tamb = 25 °C, unless otherwise specified)
PARAMETER
TEST CONDITION
PART
SYMBOL
Continuous reverse voltage
BAV19W-G
BAV21W-G
BAV19W-G
VRRM
Repetitive peak reverse voltage
VRRM
DC forward current (1)
Rectified current (average) half wave rectification with resist. load (1)
BAV21W-G
VRRM IF
IF(AV)
Repetitive peak forward current (1) f 50...
