www.vishay.com
End of Life July 2020
CP High Volume
Vishay Dale
Wirewound/Metal Oxide Resistors, Commercial Power, Axial Lead
FEATURES • High performance for low cost
• High power to size ratio
• Ceramic cases are available with circuit board stand-offs (designated with a ...3 model ending)
• Special cement potting compound and ceramic case provide high thermal conductivity in a fireproof package
• Material categorization: for definitions of compliance please see www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL MODEL
POWER RATING
P40 °C W
RESISTANCE RANGE
WIREWOUND (1)
CP0002
2
0.1 to 100
CP0003
3
0.1 to 100
CP0005
5
0.1 to 100
CP0005...3
5
0.1 to 100
CP0007
7
0.1 to 100
CP0007...3
7
0.1 to 100
CP0010
10
0.1 to 100
CP0010...3
10
0.
