SMC5K30A Transient Voltage Suppressors

www.vishay.com SMC5K10A thru SMC5K85A Vishay General Semiconductor Surface Mount TRANSZORB® Transient Voltage Suppressors SMC (DO-214AB) PRIMARY CHARACTERISTICS VBR 11.1 V to 104 V VWM PPPM TJ max. Polarity 10 V to 85 V 5000 W 150 °C Uni-directional Package SMC (DO-214AB) TYPICAL APPLICATIONS Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial,.

SMC5K30A Features

* Available in uni-directional polarity only

* 5000 W peak pulse power capability with a 10/1000 μs waveform

* Excellent clamping capability

* Very fast response time

* Low incremental surge resistance

* Meets MSL level 1, per J-STD-020, LF maximum pea
