Si8404DB
FEATURES
- Trench FET® Power MOSFET
- Industry First 1.5 V Rated MOSFET
- Ultra Small MICRO FOOT® Chipscale
Ro HS
PLIANT
Packaging Reduces Footprint Area, Profile
(0.62 mm) and On-Resistance Per Footprint Area
APPLICATIONS
- Low Threshold Load Switch for Portable Devices
- Low Power Consumption
- Increased Battery Life
MICRO FOOT
Bump Side View
Backside View
3 D
2 D
8404 XXX
S 4
G 1
Device Marking: 8404 xxx = Date/Lot Traceability Code
Ordering Information: Si8404DB-T1-E1 (Lead (Pb)-free)
S N-Channel MOSFET
ABSOLUTE MAXIMUM RATINGS TA = 25 °C, unless otherwise noted
Parameter
Symbol
Limit
Drain-Source Voltage
Gate-Source Voltage
±5
TC = 25 °C
Continuous Drain Current (TJ = 150 °C)
TC = 70 °C TA = 25 °C
9.8...
