TMPG06-13A, TMPG06-10A - Transient Voltage Suppressors

Name: TMPG06-13A
SKU: TMPG06-13A-1217254

Vishay

The TMPG06-13A by Vishay is a Transient Voltage Suppressors. Below is the official datasheet preview.

Datasheet Details

Part number	TMPG06-13A, TMPG06-10A
Manufacturer	Vishay
File Size	81.88 KB
Description	Transient Voltage Suppressors
Datasheet	TMPG06-10A-Vishay.pdf
Note	This datasheet PDF includes multiple part numbers: TMPG06-13A, TMPG06-10A. Please refer to the document for exact specifications by model.
Additional preview pages of the TMPG06-13A datasheet.

Available in uni-directional polarity only.
400 W peak pulse power capability with a 10/1000 μs waveform, repetitive rate (duty cycle): 0.01 %.
Excellent clamping capability.
Very fast response time.
Low incremental resistance.
Solder dip 275 °C max. 10 s, per JESD 22-B106.
AEC-Q101 qualified.
Material categorization: for definitions of compliance please see www. vishay. com/doc?99912.
