V4148 Small Signal Fast Switching Diodes

V4148 Description

www.vishay.com 1N4148 Vishay Semiconductors Small Signal Fast Switching Diodes DESIGN SUPPORT TOOLS click logo to get started .

V4148 Features

* Silicon epitaxial planar diode
* Electrically equivalent diodes: 1N4148 - 1N914

V4148 Applications

* Extreme fast switches Models Available MECHANICAL DATA Case: DO-35 (DO-204AH) Weight: approx. 105 mg Cathode band color: black Packaging codes / options: TR/10K per 13" reel (52 mm tape), 50K/box TAP/10K per ammopack (52 mm tape), 50K/box PARTS TABLE PART ORDERING CODE 1N4148 1N4148-

📥 Download Datasheet

Preview of V4148 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
V4148
Manufacturer
Vishay ↗
File Size
78.04 KB
Datasheet
V4148-Vishay.pdf
Description
Small Signal Fast Switching Diodes
