Description
Integrated in OVP&OCP products provider 10BJ Series 1000W Transient Voltage Suppressor .
TVS diodes can be used in a wide range of applications which like consumer electronic products, automotive industries, munitions, telecommunications,.
Features
* Glass passivated or planar junction
* Excellent clamping capability
* Repetition rate (duty cycle): 0.01%
* Low profile package and low inductance
* 1000W Peak Pulse power capability at 10×1000μs
waveform.
* Fast response time: typically less than 1.0ps from 0V
to VBR min.
