WND35P12B-A Datasheet - WeEn

WND35P12B-A, Automotive grade standard power diode

WND35P12B-A Automotive grade standard power diode Rev.01 - 26 September 2023 Product data sheet 1.General .
Automotive grade standard reverse recovery power diode in a TO263 package h RoHS alogen-Free AEC - Q101 Qualified 2.

datasheet Preview Page 1 from Datasheet4u.com

WND35P12B-A-WeEn.pdf

WND35P12B-A Datasheet Preview — Preview of WND35P12B-A PDF

Datasheet Details

Part number:

WND35P12B-A

Manufacturer:

WeEn

File Size:

494.56 KB

Description:

Automotive grade standard power diode

Features

* Low forward voltage drop
* Low leakage current
* High voltage capability
* High inrush current capability

Applications

* Input rectification
* Bypass diode
* On board and off-board xEV battery chargers 4. Quick reference data Table 1. Quick reference data Symbol Parameter Conditions Absolute maximum rating VRRM repetitive peak reverse voltage IF(AV) average forward current δ = 0.5 ; s
