S20D45C Features
* Schottky Barrier Chip H
* Guard Ring for Transient Protection
* Low Forward Voltage Drop
* Low Power Loss, High Efficiency
* High Surge Current Capability
* Epoxy Meets UL 94V-0 Classification
* Ideally Suited for Use in High Frequency SJ RK PIN1 2 3 SMPS, Inverter
Datasheet Details
S20D45C, S20D30C-Won
Won-Top
42.72 KB
20a dual schottky barrier rectifier.
This datasheet PDF includes multiple part numbers: S20D45C, S20D30C-Won.
Please refer to the document for exact specifications by model.
