Part number:
YD6282
Manufacturer:
Wuxi Youda electronics
File Size:
283.48 KB
Description:
Dual audio power amplifier.
YD6282_WuxiYoudaelectronics.pdf
Datasheet Details
YD6282 Features
* High power: Pout（1）=2.5W/CH（Typ.） (Vcc=9V, RL=4Ω, f=1kHz, THD=10%) Pout（2）=4.6W/CH（Typ.） (Vcc=12V, RL=4Ω, f=1kHz, THD=10%)
* Low popping noise at power ON
* Small quiescent current: Iccq=19mA(Typ.) @Vcc=9V, Vin=0
* Soft clip
* Built-in thermal shut down protection circuit
* Opera
