BA301 - DC to DC Converter

Product Overview

XP Power

📥 Download Datasheet

BA301 DC to DC Converter by XP Power - Datasheet Preview — Datasheet preview – BA301

Datasheet Details

Part number	BA301
Manufacturer	XP Power
File Size	45.44 KB
Description	DC to DC Converter
Datasheet	BA301 Datasheet
Additional preview pages of the BA301 datasheet.

Product details

Features

Input π Filter.
Fully Regulated Outputs.
Industry Standard Pinouts.
5, 12, 24, 28, and 48 VDC Inputs.
Ripple and Noise Less Than 50mVpp.
Input/Output Isolation Ordering Guide: Series/Input Code/Output Code Example: BC302 - BC Series, 24 Volt Input, 12 Volt Output @ 0.47A Input Code Series BA BC Output 1.5 Watts 5-6 Watts 1 2 3 4 5 Input Voltage BA/BC Series 5 V Nominal 12 V Nominal 24 V Nominal 28 V Nominal 48 V Nominal Output Code 01 02.
