Part number:
KBU1510
Manufacturer:
Yangzhou yangjie electronic
File Size:
132.27 KB
Description:
Glass passivated bridge rectifiers.
Datasheet Details
KBU1510 Features
* UL Recognized File # E-230084
* Ideal for printed circuit board
* Reliable low cost construction technique
* results in inexpensive product High temperature soldering guaranteed: 260℃ / 10 seconds / 0.375” ( 9.5mm ) lead length at 5 lbs., ( 2.3 kg ) tension .700(17.
Datasheet Details
KBU1510
Yangzhou yangjie electronic
132.27 KB
Glass passivated bridge rectifiers.
