CLV0945A
FEATURES
- 953
- Frequency Range:
- Tuning Voltage: 0.5-4.5 Vdc
- MINI-14S
- Style Package APPLICATIONS
- Digital Radios
- Satellite munications
- Pager Basestations MHz
£(f) (d Bc/Hz)
PERFORMANCE SPECIFICATIONS Oscillation Frequency Range Phase Noise @ 10 k Hz offset (1 Hz BW, typ.) Harmonic Suppression (2nd, typ.) Tuning Voltage Tuning Sensitivity (avg.) Power Output Load Impedance Input Capacitance (max.) Pushing
Pulling (14 d B Return Loss, Any Phase)
VALUE 936
- 953 -114 -15 0.5-4.5 33 3±2 50 100 <5 <5 -40 to 85 MINI-14S 4 7 APPLICATION NOTES
UNITS MHz d Bc/Hz d Bc Vdc MHz/V d Bm p F MHz/V MHz °C
Operating Temperature Range Package Style POWER SUPPLY REQUIREMENTS Supply Voltage (Vcc, nom.) Supply Current (Icc, typ.)
Vdc m A
All specifications are typical unless otherwise noted and subject to change without notice.
- AN-100/1 : Mounting and Grounding of VCOs
- AN-102 : Proper Output Loading of VCOs
- AN-107 : How to Solder Z-M VCOs
