CLV1085E-LF
TEL: (858) 621-2700 URL: .zm. EMAIL: applications@zm.
Voltage-Controlled Oscillator Surface Mount Module
Applications
Data Transmitter Digital Radios
Application Notes
AN-101: Mounting and Grounding AN-102: Output Loading AN-107: Manual Soldering
Performance Specifications Oscillation Frequency Range Phase Noise @ 10 k Hz offset (1 Hz BW) Harmonic Suppression (2nd) Tuning Voltage Tuning Sensitivity (avg.) Power Output Load Impedance Input Capacitance Pushing Pulling (12 d B Return Loss, Any Phase) Operating Temperature Range Package Style
Power Supply Requirements Supply Voltage (Vcc, nom.) Supply Current (Icc)
Additional Notes
£(f) (d Bc/Hz)
PHASE NOISE (1 Hz BW, typical)
Rev A1
Min 1050 0.5
-4
-40 Min
OFFSET (Hz)
Typ
-112 -20
21 -1 50
MINI-14S-L Typ 5 23
Max 1086
-18 4.5
85 1 1 85
Max
Units MHz d Bc/Hz d Bc Vdc MHz/V d Bm p F MHz/V MHz
°C
Units Vdc m A
LFSuffix = Ro HS pliant. All specifications are subject to change without notice.
