SFS0500A-LF
Fixed Frequency Synthesizer Surface Mount Module
Rev A1
Applications
- Data Clocks
- Test Instrumentation
- Application Notes
- AN-107: Manual Soldering Technique
- AN-205: Measuring Phase Noise for SFS Series
Performance Specifications Frequency Phase Noise @ 10 k Hz offset (1 Hz BW) Harmonic Suppression (2nd) Spurious Suppression Power Output Load Impedance Settling Time Operating Temperature Range Package Style
Power Supply Requirements Supply Voltage 1: PLL (Vcc, nom) Supply Voltage 2: VCO (Vcc, nom) Supply Current 1: PLL (Icc, typ) Supply Current 2: VCO (Icc, typ)
Reference Oscillator Signal Frequency Phase Noise @1 k Hz Offset
Additional Notes
Min
Typ
Max
Units
MHz
-114 d Bc/Hz
-13 d Bc
-70 d Bc
-2
2 d Bm
1 m S
-40
°C
PLL-V12N
Min
Typ
Max
Units
Vdc...
