SMV1205A
FEATURES
- Frequency Range: 1185
- 1225 MHz
- Tuning Voltage: 0.5-2.7 Vdc
- SUB-L
- Style Package APPLICATIONS
- Digital Cellular
- GPS
- Test Equipment PERFORMANCE SPECIFICATIONS Oscillation Frequency Range Phase Noise @ 10 k Hz offset (1 Hz BW, typ.) Harmonic Suppression (2nd, typ.) Tuning Voltage Tuning Sensitivity (avg.) Power Output Load Impedance Input Capacitance (max.) Pushing
Pulling (14 d B Return Loss, Any Phase)
OFFSET (Hz)
VALUE 1185
- 1225 -96 -11 0.5-2.7 59 0±3 50 50 <2 <7 -40 TO +85 SUB-L 3.1 8 Vdc m A UNITS MHz d Bc/Hz d Bc Vdc MHz/V d Bm
Ω p F MHz/V MHz °C
Operating Temperature Range Package Style POWER SUPPLY REQUIREMENTS Supply Voltage (Vcc, nom.) Supply Current (Icc, typ.) APPLICATION NOTES
- AN-100/1 : Mounting and Grounding of VCOs
- AN-102 : Proper Output Loading of VCOs
- AN-107 : How to Solder Z-M VCOs
All specifications are typical unless otherwise noted and subject to change without notice.
NOTES:
