V940ME02
..
9939 Via Pas ar
- San Diego, CA 92126 TEL (619) 621-2700 FAX (619) 621-2722
VOLTAGE CONTROLLED OSCILLATOR
Rev A1
PHASE NOISE (1 Hz BW, typical)
FEAT URES
- Frequency Range: 5220
- 5420 MHz
- Tuning Voltage: 0.5-4.5 Vdc
- MINI-14S-L
- Style Package APPLICATIONS
- Microwave Radios
- Satellite munications
- Direct Broadcast PERFORMANCE SPECIFICATIONS Oscillation Frequency Range Phase Noise @ 10 k Hz offset (1 Hz BW, typ.) Harmonic Suppression (2nd, typ.) Tuning Voltage Tuning Sensitivity (avg.) Power Output Load Impedance Input Capacitance (max.) Pushing
Pulling (14 d B Return Loss, Any Phase)
VALUE 5220
- 5420 -83 -25 0.5-4.5 108 -1±3 50 50 <10 <35 -30 to 85 MINI-14S-L 5 12 APPLICATION NOTES
UNIT S MHz d Bc/Hz d Bc Vdc MHz/V d Bm
Ω p F MHz/V MHz °C
Operating Temperature Range Package Style POWER SUPPLY REQUIREMENT S Supply Voltage (Vcc, nom.) Supply Current (Icc, typ.)
Vdc m A
All s pec ifications are typic al unless otherw ise noted and s ubject to change w ithout...
