V950ME08-LF
FEATURES
- Frequency Range: 4450
- 5350 MHz
- Tuning Voltage: 0-9.5 Vdc
- MINI-14S
- Style Package APPLICATIONS
- Microwave Radios
- Satellite munications
- Direct Broadcast PERFORMANCE SPECIFICATIONS Oscillation Frequency Range Phase Noise @ 10 k Hz offset (1 Hz BW, typ.) Harmonic Suppression (2nd, typ.) Tuning Voltage Tuning Sensitivity (avg.) Power Output Load Impedance Input Capacitance (max.) Pushing
Pulling ( 14 d B Return Loss, Any Phase)
OFFSET (Hz)
VALUE 4450
- 5350 -89 -22 0-9.5 120 4±3 50 50 <8 <14 -40 to 85 MINI-14S 5 27 APPLICATION NOTES Vdc m A p F MHz/V MHz °C UNITS MHz d Bc/Hz d Bc Vdc MHz/V d Bm
Operating Temperature Range Package Style POWER SUPPLY REQUIREMENTS Supply Voltage (Vcc, nom.) Supply Current (Icc, typ.)
All specifications are typical unless otherwise noted and subject to change without notice.
- AN-100/1 : Mounting and Grounding of VCOs
- AN-102 : Proper Output Loading of VCOs
- AN-107 : How to Solder Z-M VCOs
NOTES:
Phase Noise @ 100 k Hz offset (1 Hz BW,...
