ZT7184 Datasheet - ZillTek Technology

Synchronous Step-Down DC/DC Converter

ZT7184 General Description

The ZT7184 is a 340kHz fixed frequency PWM synchronous step-down regulator. The ZT7184 is operated from 4.75V to 23V, the generated output is adjustable from 0.925V to 20V, and the output current can be up to 3A. The integrated two MOSFET switches is with turn on resistance of 85mΩ. Current mode con.

ZT7184 Datasheet (354.81 KB)

Preview of ZT7184 PDF

Datasheet Details

Part number:

ZT7184

Manufacturer:

ZillTek Technology

File Size:

354.81 KB

Description:

Synchronous step-down dc/dc converter.
