LV1482SN Datasheet, Converter, ZillTek

LV1482SN Features

  • Converter
  • 4.75V to 20V input voltage
  • Output adjustable from 0.923V to 18V
  • Output current up to 2A
  • Integrated 0.085Ω power MOSFET switches
  • Shutdow

PDF File Details

Part number:

LV1482SN

Manufacturer:

ZillTek

File Size:

1.10MB

Download:

📄 Datasheet

Description:

Synchronous step-down dc/dc converter. The LV1482SN is a 550KHz fixed frequency PWM synchronous step-down regulator. The LV1482SN is operated from 4.75V to 20V, the generat

Datasheet Preview: LV1482SN 📥 Download PDF (1.10MB)
Page 2 of LV1482SN Page 3 of LV1482SN

LV1482SN Application

  • Applications
  • Distributed power systems
  • Networking systems
  • FPGA, DSP, ASIC power supplies
  • Notebook computers

TAGS

LV1482SN
Synchronous
Step-Down
Converter
ZillTek
