ADC0804

Analog-to-Digital Converter

Texas Instruments

ADC0804 Features

* 1 Compatible With 8080-µP Derivatives

* No Interfacing Logic Needed

* Access Time 135 ns

* Easy Interface to All Microprocessors, or Operates as a Stand-Alone Deivce

* Differential Analog Voltage Inputs

* Logic Inputs and Outputs Meet Both MOS and TTL

ADC0804 General Description

The ADC0801, ADC0802, ADC0803, ADC0804, and ADC0805 devices are CMOS 8-bit successive approximation converters (ADC) that use a differential potentiometric ladder

* similar to the 256R products. These converters are designed to allow operation with the NSC800 and INS8080A derivative control .

ADC0804 Datasheet (6.70 MB)

ADC0804 Datasheet Preview — Preview of ADC0804 PDF

Datasheet Details

Part number:

ADC0804

Manufacturer:

Texas Instruments ↗

File Size:

6.70 MB

Description:

Analog-to-digital converter.
