ADS1256, ADS1255 - Analog-To-Digital Converter

ADS1256 Description

ADS1255 ADS1256 SBAS288K * JUNE 2003 * REVISED SEPTEMBER 2013 Very Low Noise, 24-Bit Analog-to-Digital Converter .
D 24 Bits, No Missing Codes. All Data Rates and PGA Settings D Up to 23 Bits Noise-Free Resolution D ±0.

ADS1256 Applications

* The converter is comprised of a 4th-order, delta-sigma (ΔΣ) modulator followed by a programmable digital filter. A flexible input multiplexer handles differential or single-ended signals and includes circuitry to verify the integrity of the external sensor connected to the inputs. The selectable in

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: ADS1256, ADS1255. Please refer to the document for exact specifications by model.
