CD54HCT00J, CD54HC00 - Quadruple 2-Input NAND Gates

Texas Instruments

📥 Download Datasheet

CD54HCT00J Datasheet Preview — This datasheet PDF includes multiple part numbers: CD54HCT00J, CD54HC00. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	CD54HCT00J, CD54HC00
Manufacturer	Texas Instruments ↗
File Size	1.00 MB
Description	Quadruple 2-Input NAND Gates
Datasheet	CD54HC00-etcTI.pdf
Note	This datasheet PDF includes multiple part numbers: CD54HCT00J, CD54HC00. Please refer to the document for exact specifications by model.

CD54HCT00J Product details

Description

This device contains four independent 2-input NAND gates. B in positive logic.

Features

LSTTL input logic compatible.
VIL(max) = 0.8 V, VIH(min) = 2 V.
CMOS input logic compatible.
II ≤ 1 µA at VOL, VOH.
Buffered inputs.
4.5 V to 5.5 V operation.
Wide operating temperature range:.
55°C to +125°C.
Supports fanout up to 10 LSTTL loads.
Significant power reduction compared to LSTTL logic ICs 2.
