LM134

3-Terminal Adjustable Current Sources

Texas Instruments

LM134 Features

* 1

* 2 Operates From 1V to 40V

* 0.02%/V Current Regulation

* Programmable From 1μA to 10mA

* True 2-Terminal Operation

* Available as Fully Specified Temperature Sensor

* ±3% Initial Accuracy DESCRIPTION The LM134/LM234/LM334 are 3-terminal adjustable c

LM134 General Description

The LM134/LM234/LM334 are 3-terminal adjustable current sources featuring 10,000:1 range in operating current, excellent current regulation and a wide dynamic voltage range of 1V to 40V. Current is established with one external resistor and no other parts are required. Initial current accuracy is ±3.

LM134 Datasheet (1.50 MB)

LM134 Datasheet Preview — Preview of LM134 PDF

Datasheet Details

Part number:

LM134

Manufacturer:

Texas Instruments ↗

File Size:

1.50 MB

Description:

3-terminal adjustable current sources.
LM134, LM234, LM334 www.ti.com SNVS746E

* MARCH 2000

* REVISED MAY 2013 LM134/LM234/LM334 3-Terminal Adjustable Current Sources Che.
