OPA322 Datasheet, Amplifier, Texas Instruments

OPA322 Features

• Amplifier
• 1 Gain Bandwidth: 20 MHz
• Low Noise: 8.5 nV√Hz at 1 kHz
• Slew Rate: 10 V/μs
• Low THD+N: 0.0005%
• Rail-to-Rail I/O
• Offset Voltage:

PDF File Details

Part number:

OPA322

Manufacturer:

Texas Instruments ↗

File Size:

2.76MB

Download:

📄 Datasheet

Description:

Cmos operational amplifier. The OPAx322x series consists of single, dual, and quad-channel CMOS operational amplifiers featuring low noise and rail-to-rail input

OPA322 Application

• Applications
• Sensor Signal Conditioning
• Consumer Audio
• Multi-Pole Active Filters
• Control-Loop Amplifiers
