TL494 Datasheet, controller equivalent, Texas Instruments

TL494 Features

• Controller
• Complete PWM Power-Control Circuitry
• Uncommitted Outputs for 200-mA Sink or Source Current
• Output Control Selects Single-Ended or Push-Pull Operation

PDF File Details

Part number:

TL494

Manufacturer:

Texas Instruments ↗

File Size:

1.54MB

Download:

📄 Datasheet

Description:

Pulse-width-modulation controller. The TL494 device incorporates all the functions required in the construction of a pulse-widthmodulation (PWM) control circuit on a si

TL494 Application

• Applications
• Desktop PCs
• Microwave Ovens
• Power Supplies: AC/DC, Isolated, With or Without PFC
• Server PSUs
