NMV2409DAC Datasheet, Converters, muRata

NMV2409DAC Features

• Converters
• RoHS compliant
• Efficiency to 85%
• Power density up to 0.85W/cm3
• Single or dual output
• UL 94V-0 package material
• No heatsink req

PDF File Details

Part number:

NMV2409DAC

Manufacturer:

muRata

File Size:

124.91kb

Download:

📄 Datasheet

Description:

3kvdc isolated 1w single & dual output dc/dc converters. The NMV series offers single or dual output versions in the same size package as the popular NMA series. The higher isolation is part

NMV2409DAC Application

• Applications where the standard 1kV is not sufficient. Nominal Input Voltage Output Voltage Output Current Load Regulation (Max) Ripple & Noise (Max
