Description
SMB P6SMB series 600 W Transient Voltage Suppressor 2 January 2025 Product data sheet 1.General .
600 W uni- and bi-directional Transient Voltage Suppressor (TVS) in a SMB Surface-Mounted Device (SMD) plastic package, designed for transient voltage.
Features
* Rated peak pulse power at 10/1000 μs waveform: PPPM = 600 W
* Reverse standoff voltage: VRWM = 7.02 V to 214 V
* Reverse current: IR less than 1 μA for VRWM ≥ 11.1 V
* Excellent clamping capability
* Small plastic package suitable for surface-mounted design
Applications
* Power supply protection
* Power management
* Telecom, Computer, Industrial and Consumer electronics application
4. Quick reference data
Table 1. Quick reference data
Symbol
Parameter
Conditions
VRWM
reverse standoff voltage
Tamb = 25 °C
PPPM
rated peak pulse power
